類別：固裝系列
簡介： Quick p6.667 fixed install led display billboard for sportsis one of the widely used led display in themarket now, usually applied in commercial ads, stadium, stage rental...... Features: 1. High definition 2. IP65 protection 3. frontmaintenancedesign 4. high cost performance, 30% cheaper. OutdoorP6.667ledscreen ...
Quick p6.667 fixed install led display billboard for sports is one of the widely used led display in the market now, usually applied in commercial ads, stadium, stage rental......
Features:
1. High definition
| Outdoor P6.667 led screen | |
| Physical parameters | |
| Pixel pitch | P6.667 |
| Physical density | 22498 dots/m2 |
| Led packing | SMD3535 |
| LED composition | 1R1G1B |
| Cabinet size | 640x640mm/960x960mm |
| Caninet weight | 7.5kg/28kg |
| Cabinet material | Die-casting aluminum |
| Optoelectronic parameters | |
| AC operation voltage | 100~120V/220~240V |
| Scan | 1/6 S |
| Brightness | 6000cd/m2 |
| Gray level | 14 bit |
| View distance | 6~50m |
| View angel | 140 degree horizon/vertical |
| Refresh rate | ≥1920 |
| Life span | 100,000h |
| Frame frequency | ≥60Hz |
| IP rate | indoor IP30/outdoor IP65 |
